NO DESCRIPTION QTY NO DESERIPTION QTY
D-01 Blade nut M16(left hand) 1 D-39 HANDLE 2
D-02 Outer blade washer 1 D-40 Handle bolt 2
D-03 Blade 1 D-41 Cross recessed pan head screw
M6×16
4
D-04 A-belt 1
D-05 Pulley 1 D-42 Flat washer 6 8
D-06 Key A-type 1 D-43 Ball bracket 2
D-07 Arbor shaft 1 D-44 Thread rod ball 1
D-08 Bearing 80203 2 D-45 Spring dowel 4×28 1
D-09 Arbor shaft sleeve 1 D-46 Adjusting thread rod 1
D-10 Arbor shaft bush 1 D-47 Worm-wheel connecting rod nail A 1
D-11 Circlips for hole D=40 2 D-48 Worm-wheel connecting rod 1
D-12 Arbor shaft end bush 1 D-49 Worm-wheel connecting rod nail B 1
D-13 Press washer 1 D-50 Connecting rod bush 1
D-14 Single coil spring lock washer 6 1 D-51 Hexagon nut M6 4
D-15 Hexagon head bolt M6×16 1 D-52 Adjusting frame 1
D-16 Hexagon head bolt M8×20 2 D-53 Circlips for shaft D=24 2
D-17 Flat washer 8 18 D-54 Knuckle 1
D-18 Press board for riving knife 1 D-55 Hexagon socket cap head screw
M6×12
1
D-19 Riving knife 1
D-20 Flower nut 1 D-56 Height adjustment rod 1
D-21 Large washer 6 2 D-57 Circlips for shaft D=18 1
D-22 Step bolt M6×46 1 D-58 Motor 1
D-23 Blade guard 1 D-59 Hexagon head bolt M8×40 7
D-24 Hexagon nut M8 13 D-60 Key 8×7×50 1
D-25 Hexagon sockert set screw with flat
point M8×25
4 D-61 Hexagon socket set screw with flat
point M6×9
1
D-26 Hexagon socket cap head screw
M10×30
1 D-62 Hexagon socket set screw with flat
point M6×6
1
D-27 Locking nut with plastic insert M8
screw M8×30
1 D-68 Hexagon head bolt M8×75 1
D-69 Hexagon nut M12 1
D-33 Hexagon head bolt M8×65 1 D-70 Single coil spring lock washer 12 1
D-34 Locking nut for motor base 2 D-71 Worm-wheel 1
D-35 Motor base 1 D-72 Eccenrtic sleeve 1
D-36 Hexagon socket cap head screw
