MacMah MJ2325A - Page 31

NO. DESCRIPTION Q’TY
F-42 Girclips for shaft d=14
1
F-43 Press block shaft
1
F-44 spring
1
F-45 Eccentric shaft
1
F-46 Girclips for shaft d =8
1
F-47 Glamp base
1
F-48 Glamp block
1
F-49 Knurling screw
1
F-50 Long rail
1
F-51 Short rail
1
F-52 Supporting and connection plate of rail
2
F-53 Brace tube
1
F-54 Hex nut M12
2
F-55 Screw pole
1
F-56 Support of screw pole
1
F-57 Supporting block
2
F-58
Hex head screw M8
×40
2
F-59 Tilt bracket for sliding table
1
F-60
Hex head screw M8
×18
4
F-62 Bearing frame sleeve
8
F-63
Hex socket cap head screw M8
×32
12
F-64 Fence block nut
1
F-65 Fence block base
1
F-66
Adjustable hadnle screw M8
×25
1
F-67
Slotted set screw with flat point M5
×12
1
F-68 Fence
1
F-69 Flat washer 10
1
F-70
Hexagon socket cap head screw M10
×20
1
F-71 Long strip nut
1
F-73 Spring washer 12
4
F-74 Flat washer 12
4
F-75 Hex nut M12
4
