Maco MULTI - Setting the Closing Element, Setting the Sash Lifter

- 13 -
MACO
MULTI
15
-0,55 / +0,5
5
-0,75 / +0,75
9
+
+
-3 / +3
15
-3 / +3
15
-0,5 / +0,5
-2 / +2
4
MULTI-MATIC MULTI-TREND
Setting the closing element, the bullet
catch and the sash lifter
■ Setting the gasket compression on the cam
■ Setting the sash lifter
■ Setting the door catch and/or the bullet catch roll
i.S. Security roller cam
Locking cam
