- 2 -
MACO
MULTI
Contents
Safety and warning information 3
Measures to preserve the surface finish 5
Setting the turn-only, turn&tilt and tilt-first sash
Setting the scissor stay or turn-only hinge - sash part – lift/lower 6
Setting the scissor stay or turn-only hinge – gasket compression 7
Pivot post setting 9 - 10
Tilt-only sash setting 12
Setting the closing element, setting the sash lifter 13
Hinging and unhinging the sash 14 - 15
These maintenance instructions are only intended for
certified specialists and their trained employees.
In addition to these maintenance instructions, the
operation and maintenance instructions for the end user
must always be observed.
These instructions can also be downloaded from
www.maco.eu, order number 757071.
