16
The pilot isolator must not be
tampered with or deactivated in any
way. Never operate the machine
from anywhere but the operators
seat.
Key Switch
OFF – Disconnects all electrical power, Turn to OFF position to shut down engine.
Leave key in this position when machine is not operating.
RUN – Battery is connected and electrical function is regained, Key will stay in this
position while engine is running.
START – This will start the engine by connecting the battery to the start relay, hold
here until engine starts. Once released the key will return to RUN position.
Pilot isolator
This safety feature is provided to prevent
accidental and improper use of the hydraulic
controls. The pilot isolator requires the
operator to be seated to unlock hydraulic
functions.
Air Conditioning Unit
The air conditioning unit in your Madill machine must be cycled on a bi-weekly basis to
ensure that the compressor seals remain lubricated.
Refrigerant may leak from the compressor if the unit is not run regularly, particularly
over the fall and winter months. The air conditioner warranty does not cover claims for
refrigerant loss that are compressor seal related if the unit has not been run on a
regular basis.
Travel - Left & Right Pedals
To maximize undercarriage component life keep the drive sprockets to the rear of the
machine. This orientation is assumed for travel direction descriptions.
FORWARD Depress front of both pedals
REVERSE Depress rear for both pedals
STEER LEFT Depress front of right pedal and rear of left pedal to steer left
STEER RIGHT Depress front of left pedal and rear of right pedal to steer right
Diagnostic Plug
Located in the right arm rest, allows for quick and easy connection of diagnostics
equipment.
