NTWB1
Installation & User Manual
Rev 0.3
2 Installation
2.1 Installation
2.1.1 Overview
The NTWB1 can be mounted to any flat surface inside the boats cabin
where it will be protected from water and mechanical damage.
The NTWB1 does not need to be in direct line of sight of the WiFi devices
which will connect to it so can be hidden out of view if desired, however
the fewer obstructions between the NTWB1 and connected WiFi devices
the better the reception performance will be.
2.1.2 Mounting Location
The following must be taken into account when selecting a
mounting location:
Room to attach the antenna,
Ability to view the LED indicators,
Obstructions between NTWB1 and other WiFi devices,
Protection from water (including condensation) and mechanical
damage,
Proximity to equipment or cabling which could cause interference to
or be interfered by the NTWB1.
There are two flanges on the NTWB1 enclosure which have holes
provided for mounting to any flat surface with screws (2 required).
Alternatively self-adhesive Velcro could be used to mount the NTWB1 in
any convenient location. Refer to Illustration 2 for flange locations.
5
