5
Power Supply
Be careful when handling the device and electrical power! To supply the unit with
power, first connect the provided power cable to the unit (‘Power’) and then to
a suitable power outlet. The device works with mains voltage (AC 100-240V)!
CAUTION!
RISK OF ELECTRICAL SHOCK. DO NOT OPEN THE UNIT.
Description Of Status LED Codes
The following tables describe the LED status codes on the front of the device.
STATUS POWER
Powered off
Power cable not connected.
The device has no power.
Permanently green
Connected to power.
The power is on.
STATUS ETHERNET USB
Powered off
Ethernet not connected
or the device has no power.
USB not connected
or the device has no power.
Permanently green
Connected to Ethernet.
No data is sent or
received over Ethernet.
Connected to USB.
No data is sent or
received over USB.
Blinking green
Communicating over
Ethernet.
Sending or receiving data
over Ethernet.
Communicating over
USB.
Sending or receiving data
over USB.
STATUS DMX-IN DMX-OUT
Powered off
DMX not connected
or the device has no power.
DMX not connected
or the device has no power.
Blinking green
Receiving data via DMX-IN.
The interface works
correctly.
Sending data to DMX-OUT.
The interface works
correctly.
