-28-
Defect
Cause
Elimination
Machine stops while drilling is in
process
Mains failure
Check mains back-up fuses
Burn marks on the drill holes
Feed speed too low
Increase feed speed
Blunt drill bit
Regrind drill bit or replace
Chip ejection blocked
Wood is too damp
Extended drilling without
extraction
Connect machine to an external
extraction, e.g. portable dust
extractor
8 Optional accessories
- Dowel drill bit - HS-TiN Ø 3 mm (0.118 in.)
Order No. 090 083
- Dowel drill bit - HM Ø 5 mm (0.196 in.)
Order No. 090 089
- Dowel drill bit - HM Ø 6 mm (0.236 in.)
Order No. 090 096
- Dowel drill bit - HM Ø 6.1 mm (0.240 in.)
Order No. 090 120
- Dowel drill bit - HM Ø 8 mm (0.314 in.)
Order No. 090 097
- Dowel drill bit - HM Ø 8.1 mm (0.318 in.)
Order No. 090 122
- Dowel drill bit - HM Ø 8.2 mm (0.322 in.)
Order No. 090 123
- Dowel drill bit - HM Ø 10 mm (0.393 in.)
Order No. 090 098
- Dowel drill bit - HM Ø 10.1 mm (0.397 in.)
Order No. 090 124
- Dowel drill bit - HM Ø 10.2 mm (0.401 in.)
Order No. 090 125
- Dowel drill bit - HM Ø 12 mm (0.472 in.)
Order No. 090 099
- Dowel drill bit - HM Ø 12.2 mm (0.480 in.)
Order No. 090 127
- Lateral stop set SA 320
Order No. 206 490
- Trim stop LA
Order No. 206 491
- Dowel drilling template clamping device, 800 mm (31.496 in.)
Order No. 203 980
- Dowel drilling template extension 1600 cpl., length 1600 mm (62.992 in.)
Order No. 203 434
- Screw clamp with stop (for working with dowel drilling template extension)
Order No. 093 280
- Screw clamp (for rail fixing on the workpiece)
Order No. 093 281
- Wood dowel see specialised trade, DIY store etc.
9 Exploded drawing and spare parts list
The corresponding information in respect of spare parts can be found on our homepage: www.mafell.com
