Mafell MT 55 cc - Technical Data; Emissions; Scope of Supply

-19-
2.3 Technical data
Universal motor, radio and TV interference suppressed
230 V~,
50 Hz
110 V~,
50 Hz
120 V~,
60 Hz
Power input (nominal load)
1400 W
Current at nominal load
7,0 A
13,5 A
13,5 A
Saw blade speed during idling
3600 - 6250 rpm
Saw blade speed at normal load
3600 - 6250 rpm
Cutting depth
57 mm (2 1/4 in.)
Swivelling saw unit
-1°/ 0°- 48°
Saw blade diameter max/min
162/149 mm (6 3/8 / 5 7/8 in.)
Saw blade body thickness
1.2 mm (3/64 in.)
Tool cutting width
1.8 mm (5/64 in.)
Saw blade mounting hole
20 mm
Hose connector diameter
35 mm (1 3/8 in.)
Weight without mains cable, without parallel guide fence
4,5 kg (9.9 lbs)
Dimensions (W x L x H)
228 x 365 x 220 mm (9 x 14 3/8 x 8 5/8
in.)
2.4 Emissions
The declared noise emission values have been measured in accordance with DIN EN 62841-1 and DIN EN
62841-2-5 and may be used for comparing the tool with another and also in a preliminary assessment of
exposure.
Danger
The noise emissions during actual use of the power tool can differ from the declared
values depending on the ways in which the tool is used especially what kind of
workpiece is processed.
Always wear hearing protection, even when the power tool ist running idle in addition
to the trigger time!
2.4.1 Noise emission specifications
Noise emission values determined according to EN 62841:
Sound pressure level
L
PA
= 93 dB (A)
Uncertainty
K
PA
= 3 dB (A)
Sound power level
L
WA
= 104 dB (A)
Uncertainty
K
WA
= 3 dB (A)
The noise measurement was recorded using the saw blade included in the standard equipment.
2.4.2 Vibration specifications
The typical hand-arm vibration according to EN 62841 is less than 2.5 m/s
2
.
2.5 Scope of supply
Portable circular saw MT 55 cc complete with:
1 carbide-tipped circular saw blade Ø 162 mm (6 3/8 in.), 48 teeth
1 parallel guide fence (not on models MidiMAX)
