120 Operating Manual MT 25 / 30 YT
Lifting
Fig. 105: Front sling points
1 Front sling points
2 Transmission cover
Fig. 106: Rear sling point
X
Attach the hoisting equipment to the points intended for this.
3 The MT can be hoisted now carefully and loaded away.
During lifting, the MT tilts forward slightly so that the
hoisting equipment cannot damage the driver's cab.
