OPERATION
OPERATING PANEL FOR AUTOMATIC TRANSMISSION
Operating Manual MT 25 / 30 YT 73
The error code in “d1” is displayed until you switch to
the next code by pressing MODE KEY
3 or you end the
read out of the error codes.
Reading current and saved error codes
X Press the MODE key 3 to read out the current and saved
error codes.
In the display 5, the error codes appear one after the other
by pressing the MODE key.
By pressing the MODE-ON key 4 you can differ between the
current and saved error codes:
z The MODE-ON LED indicator is lit when the displayed
error code is active, i.e. is current.
z The MODE-ON LED indicator goes out when the displayed
error code is inactive, i.e. has been saved.
Ending diagnostics mode
To exit the diagnostics mode, perform one of these three
steps:
z Do nothing; wait until the system automatically returns to
normal operation.
z Press arrow keys 1 and 2 simultaneously.
z Press the key N on the operating panel for neutral
operation.
