MAFI Trac T225 - Page 79

OPERATION
COMBINATION DISPLAY INSTRUMENT
Operating manual T225 / T230 77
Speedometer
Fig. 71: Speedometer
1 Driving speed
2 Operating hours counter
The driving speed is displayed in two units.
z grey = display in km/h (kilometres per hour)
z yellow = display in mph (miles per hour)
The operating hour counter can be found on the lower part of
the speedometer. The operating hour counter runs as soon as
the battery charge indicator goes out.
Fuel gauge
Fig. 72: Fuel gauge
The fuel gauge is operational when the ignition is on. It takes
a moment though for the pointer to reach its destination.
If the pointer has reached the reserve region (marked red),
then there is approx. ??? % of the tank's content remaining.
Do not ever run the tank empty. If the tank has been
run empty, the fuel system has to be de-aerated.
11-C26-067-045A-1
km/h
MPH
00000 00
0
10
20
30
40
50
60
0
10
20
40
MPH
km/h
4/4
1/2
11-C26-067-051A-2
0
1/2
1
