Installation 4
Cleaning the Area
Use the alcohol pad that came with the Magellan Maestro to clean the area on the windshield or dash
that has been selected for mounting the Magellan Maestro. Let the area dry completely.
Applying the Adhesive Disk
(Skip if mounting directly to the windshield.)
Remove the protective tape from the back of
the adhesive disk. Apply the disk with the
adhesive side towards the dash. Maintain
pressure on the disk for 5 minutes to allow it
to set in place. Allow the disk 24 hours to
cure before continuing.
Attach the Cradle to the Swivel Mount
Line up the two tabs on the swivel mount
with the holes on the back of the cradle.
Push the cradle down until it locks in place
with the swivel mount.
Secure the Swivel Mount to the Windshield or Adhesive Disk
Make sure that the lever at the base of the
adjustable mount is in the up position. Place
the base of the swivel mount firmly over the
area of the windshield to be used or the
adhesive disk. Push the lever at the base of
the swivel mount all the way down until it
snaps in place. Carefully let go of the
assembly, making sure that it is securely
mounted.
