8 User Guide
Trouble Display
Your alarm system continuously monitors several trouble conditions that can be reported directly to your monitoring station. When a
trouble condition occurs, the [
TBL] key will illuminate. We strongly suggest that you inform your monitoring station of the trouble and
allow them to service your system.
The keypad can be programmed to emit a BEEP every 5 seconds whenever a new trouble condition has occurred. Press the [TBL]
key to stop the “Trouble Beep”.
Trouble List
[1] Wireless Zone Low Battery: The battery voltage in one or more wireless zones is getting low.
[2] Power Trouble: The control panel is experiencing low/no battery, there is an AC failure on the control panel, or there is an
auxiliary overload on the control panel.
[3] Bell Trouble: There is a bell disconnect/overload on the control panel.
[4] Communication Trouble: Your alarm system, if monitored, could not communicate with the monitoring station.
[5] Tamper/Zone Wiring Failure: A wiring problem is occurring on one or more zones.
[6] Module Tamper Trouble: A module’s anti-tamper switch has been triggered.
[7] Fire Loop Trouble: Indicates a wiring trouble on a fire zone.
[8] Timer Loss: Your alarm system’s clock must be reprogrammed. This is the only trouble that we recommend that you
correct.
[9] Wireless Zone Supervision Loss: One or more wireless zones are no longer communicating with the control panel.
[10] Module Supervision Loss: One or more modules are no longer communicating with the control panel.
How do I access the Trouble Display?
1. Press the [TBL] key.
The [TBL] key will flash and number(s) corresponding to the trouble(s) will illuminate.
2. Read the corresponding explanation of the trouble from the Trouble List below. If no repair instructions are given, call your
monitoring station for repairs.
3. Press the [CLEAR] key to exit.
How do I reprogram the clock?
1. Press [8] for Timer Loss.
2. Enter the hour and minutes. If the hour is between 01 and 12, you will need to select [1] for 24Hr format, [2] for AM, and [3] for
PM setting. If the hour is above 12, the system will automatically select the 24Hr format.
3. Enter the year (4 digits).
4. Enter the month (2 digits).
5. Enter the day (2 digits). You have now set the Time & Date. Press [
CLEAR] to exit.
