6
A-3. Mounting microwave oven
NOTE: IT IS VERY IMPORTANT THAT THIS OVEN BE INSTALLED BY TWO PEOPLE.
PREPARATION OF TOP CABINET
You need to drill holes for the top support screws and a hole large enough for the power cord to fit through.
• Read the instructions on the TOP CABINET TEMPLATE
• Tape it underneath the top cabinet
• Drill the holes, following the instructions on the template
Step. 1
Protect the top of your range by placing a portion of the carton or some other heavy material over the cooking surface before
mounting your oven.
Step. 2
Hang the unit on the two tabs at the bottom of the mounting plate.
Step. 3
Thread power cord through the hole at the bottom of the top cabinet.
Swing the unit upward to meet the top of the mounting plate and hold
secure.
NOTE:TOP CABINET TEMPLATE instruction must be complete to proceed.
