THE QUICK FAUCET ADAPTER EASILY CONNECTS TO THE SINK FAUCET.
A) First remove aerator from your faucet nozzle and a!ach the quick connect threaded
adapter to the faucet. The quick connect faucet adapter allows easy snap-on/snap-
off connec#on to standard (7/8” diameter) faucets.
B) Connect the dishwasher Quick Connect Faucet Adapter to the faucet first to ensure
the hose length fits the dishwasher’s selected loca#on. Both hose and fi%ngs must
be connected to the back of the dishwasher. The plas#c water intake and drain
fi%ngs are unique to each design and are made to easily fit the dishwasher.
A hose that a!aches to a sink spray can burst if it is installed on the same
water line as the dishwasher. If your sink has a sink spray, it is recommended that the hose
be disconnected and the hole plugged.
C) Water Intake Hose: Connect to the rear of the dishwasher using the large, 4-corner
shaped wing nut.
D) Drain Hose: Connect to the rear of the dishwasher. It is suggested you use pliers to
#ghten but DO NOT over #ghten.
1) Drain Port Connec#on 5) Faucet Adapter 9) Locking Collar
2) Quick Connect Connec#on 6) Faucet Washer 10) Inlet Hose Connec#on
3) Inlet Port Connec#on 7) Pressure Relief Value 11) Drain Hose Connec#on
4) Quick Connect Connec#on 8) Faucet Adapter Connec#on
QUICK FAUCET ADAPTER CONNECTION
WARNING
!
WARNING
!
ghten but DO NOT over #ghten.
or
t
Co
nn
ec
#o
n
5
)
Fa
uc
et
A
da
pt
er
9)
L
oc
ki
ng
C
ol
la
r
-PAGE 9-
