10
PART # QTY ITEM PAGE
10002 Plastic spacer 2 1
10003 Vibro mount 2 2
10009-2 Rubber cover 1 3
10017 Bolt ½ 2 4
10018 Nut ½ 2 5
10019 Washer ½ 4 6
10023 Washer 8 mm 8 7
10024 Nut 8 mm 16 8
10025 Drive axle 1 9
20013-1 Stand 1 10
20014 Stand rubber 1 11
20017 Bolt ¼ 5 12
20018 Nut ¼ 5 13
20023 6 mm nylon for stand 2 14
20026 Tie rap 2 15
20027 Pop 1/8 for stand rubber 2 16
20032-2 Adj. Hdl. Grip section 2 17
20032-3 Adj. Hdl. Long section 2 18
20033 Clip for handles 4 19
20040 Tie rap 1 21
50002 Anti-vibration seal 1 22
50005 Cap 8 23
50009 Rubber tube 1 32
E-60002 E-Screed Handle 1 24
E-60003 Bolt Plastic Cover 25
E-60004 E-Screed Grip 2 26
E-60123 Housing Weight Shaft 1 27
E-60124 Housing Weight E-screed 1 28
E-60125 Counter Weight E-Screed 1 29
E-60126 Circlip 15 1 30
E-60140 Battery Pack 1 8
E-60141 Battery Charger 1 8
E-60200 Housing Weight Bearing 2 31
KE5010 Motor and gear box kit 1 8
KE5020 Plastic cover kit 1 9
KE5030 Throttle 1 9
KE5040 Control Box 1 9
KE-5050 Bolt Controller Box 9
KE5070 Charger Europe 1 9
KE5080 Battery Wire 1 9
MAGIC SCREED PARTS BOOK 2013
DESCRIPTION
To Next Page
