MAGIC SCREED HD7070 - Page 8

8
E-SCREED PARTS ASSEMBLY
DA 4097 ALLEN 6 MM 5 MM
PART NUMBER QTY DESCRIPTION
10056 1 ALLEN 6 MM 5 MM
DA 4098 TIE RAP FOR 10009-2
PART NUMBER QTY DESCRIPTION
20040 10 TIE RAP
DA 4099
PART NUMBER QTY DESCRIPTION
20026 10 TIE RAP FOR HANDLES
DA 4100
PART NUMBER QTY DESCRIPTION
50002 1 ANTI VIBRATION SEAL
10024 8 NUT 8 MM
DA 4101
PART NUMBER QTY DESCRIPTION
50005 8 CAP FOR 8 MM NUT
E-60004 E-SCREED GRIP ASSEMBLY
PART NUMBER QTY DESCRIPTION
20012 1 GRIP (SET OF 2)
E-60140 BATTERY PACK ASSEMBLY
PART NUMBER QTY DESCRIPTION
E-60140 1 BATTERY PACK
E-60141 BATTERY CHARGER
PART NUMBER QTY DESCRIPTION
E-60141 1 BATTERY CHARGER
