6
Attach the jog dial to the jog dial insertion slot
7
Turn the jog dial in the anti-clockwise direction
The card is discharged from the card outlet.
8
Restore the jog dial to its original position
9
Remove any slack in the laminate film
If the film is entangled, refer to (
A
page 34 “Film is
Entangled”).
●
●
10
Insert the film cassette all the way in along the
guide rail until a “click” sound is heard, and close
the laminator door
Cautions:
Make sure to insert the film cassette all the way in until
a “click” sound is heard. Failure to do so may result in
defective patch or card jam.
If the film cassette is inserted upside down, it cannot
be inserted all the way in and the cassette button does
not lock in place. Also, you will not be able to close the
laminator door.
●
●
Orange
Yellowish-
green
To Next Page
