Page 10 of 19 507388-03Issue 2110
Model
Rise
Range
(°F)
Mid
Rise
(°F)
Indoor Blower
Speed
Unit Voltage
(V)
0.1“ w.c. 0.2“ w.c. 0.3“ w.c. 0.4“ w.c.
SCFM
Temp
Rise
(°F)
SCFM
Temp
Rise
(°F)
SCFM
Temp
Rise
(°F)
SCFM
Temp
Rise
(°F)
HWC8N2412P12A 25 - 55 40
TAP 1 (HEAT) *
208 or 230 455 39 415 43 385 46 355 50
TAP 2 (HEAT)
208 or 230 570 31 540 33 510 35 485 37
TAP 3 (HEAT)
208 or 230 655 27 625 28 595 30 575 31
TAP 4 (COOL) †
208 or 230 480 460 440 415
TAP 5 (COOL)
208 or 230 530 505 485 460
HWC8N3612P12A 35 - 65 50
TAP 1 (HEAT)
208 or 230 455 59 415 N/A 385 N/A 355 N/A
TAP 2 (HEAT) *
208 or 230 570 47 540 50 510 53 485 55
TAP 3 (HEAT)
208 or 230 655 41 625 43 595 45 575 47
TAP 4 (COOL) †
208 or 230 480 460 440 415
TAP 5 (COOL)
208 or 230 530 505 485 460
HWC8N3612P18A 25 - 55 40
TAP 1 (HEAT) *
208 or 230 630 42 600 44 570 47 550 48
TAP 2 (HEAT)
208 or 230 770 35 740 36 715 37 690 39
TAP 3 (HEAT)
208 or 230 885 30 855 31 830 32 810 33
TAP 4 (COOL) †
208 or 230 560 540 520 500
TAP 5 (COOL)
208 or 230 610 580 560 535
HWC8N4812P18A 35 - 65 50
TAP 1 (HEAT)
208 or 230 630 56 600 59 570 62 550 N/A
TAP 2 (HEAT) *
208 or 230 770 46 740 48 715 50 690 52
TAP 3 (HEAT)
208 or 230 885 40 855 42 830 43 810 44
TAP 4 (COOL) †
208 or 230 560 540 520 500
TAP 5 (COOL)
208 or 230 610 580 560 535
HWC8N6012P18A 45 - 75 60
TAP 1 (HEAT)
208 or 230 630 71 600 N/A 570 N/A 550 N/A
TAP 2 (HEAT)
208 or 230 770 58 740 60 715 62 690 64
TAP 3 (HEAT) *
208 or 230 885 50 855 52 830 54 810 55
TAP 4 (COOL) †
208 or 230 560 540 520 500
TAP 5 (COOL)
208 or 230 610 580 560 535
HWC8N3612P24A 25 - 55 40
TAP 1 (HEAT) *
208 or 230 630 42 600 44 570 47 550 48
TAP 2 (HEAT)
208 or 230 770 35 740 36 715 37 690 39
TAP 3 (HEAT)
208 or 230 885 30 855 31 830 32 810 33
TAP 4 (COOL) †
208 or 230 770 750 730 710
TAP 5 (COOL)
208 or 230 820 790 770 750
HWC8N4812P24A 35 - 65 50
TAP 1 (HEAT)
208 or 230 645 55 615 58 590 60 565 63
TAP 2 (HEAT) *
208 or 230 780 46 755 47 730 49 710 50
TAP 3 (HEAT)
208 or 230 900 40 875 41 855 42 835 43
TAP 4 (COOL) †
208 or 230 770 750 730 710
TAP 5 (COOL)
208 or 230 820 790 770 750
HWC8N6012P24A 45 - 75 60
TAP 1 (HEAT)
208 or 230 645 69 615 72 590 N/A 565 N/A
TAP 2 (HEAT)
208 or 230 780 57 755 59 730 61 710 63
TAP 3 (HEAT) *
208 or 230 900 49 875 51 855 52 835 53
TAP 4 (COOL) †
208 or 230 770 750 730 710
TAP 5 (COOL)
208 or 230 820 790 770 750
N/A: Do not operate unit in heating mode using this blower speed at this external static pressure outside of the proper temperature rise range.
NOTE: HWC**30A models shipped with Low and High stage Cooling taps connected for use of the two-stage system.
* As shipped speed for Heating operation
† As shipped speed for Cooling operation
Table 2. Supply Airow Performance (SCFM) as a Function of External Static Pressure
