507388-03 Issue 2110 Page 3 of 19
Installation
General
These instructions must be hung on or near the furnace in
a conspicuous place.
The MagicPak All-In-One™ HVAC system model HWC8
V-Series™ units are self-contained, gas-red heating
with electric cooling models. The unit design has been
certied by Intertek Testing Services for compliance with
the latest edition of the American National Standard ANSI
Z21.47 for direct vent central furnaces. The HWC8 models
are certied to be in compliance with the latest edition of
A.H.R.I. Standard 210/240. All models are design certied
for heating operation when red with natural or propane
gas.
These installation instructions are intended as a general
guide only, for use by an experienced, qualied contractor.
Inspection
The unit is shipped in one package, completely assembled
and wired. The Evaporator drain tubing is in the cooling
compartment behind the lter access panel.
If any damage is found, proper notation should be made on
the carrier’s freight bill. Damage claims should be led with
the carrier as quickly as possible.
Check the rating plate to conrm heating and cooling
capacities. The unit should be operated only with the type
of gas and electrical supply noted on the rating plate.
In the State of Massachusetts:
This product must be installed by a licensed Plumber
or Gas Fitter. When exible connectors are used, the
maximum length shall not exceed 36”. When lever-type
gas shuto󰀨s are used, they shall be T-handle type.
WARNING
NOTE: Remove the chassis hold down shipping bracket
before installation. These brackets are located on the
outdoor side of the unit below the louver panels.
Location
The design is certied for indoor installation only. The
interior portions of the unit may be surrounded by a closet
with minimum clearances to combustible material held
to 0” sides, 2” top, and 1” front and plenum. Adequate
clearance must be provided to install gas line union and
manual shuto󰀨 valve as well as providing accessibility for
eld wiring. Do not install directly on carpeting, tile, or other
combustible material other than wood ooring.
The grille side of the unit may be ush with, or extend
beyond, the face of the exterior wall, but should not be
recessed more than 2” from the face of the building and
should not be obstructed with trees, landscape materials,
or building structure.
There is no minimum clearance required on locating the
unit to an interior corner of a building.
If the unit is to be enclosed, provisions should be made
allowing access to the indoor side of the unit for changing
lters and for inspection. At least 29” of unobstructed space
should be provided in front of the indoor side, whether
enclosed or not, to permit removal of the cooling chassis
should repairs or inspection be required.
If the unit is installed in a residential garage, it must be
located or protected to avoid physical damage by vehicles.
Unit must be installed so the burners and ignition source
are not less than 18” (457 mm) above the oor. This unit
must be installed so that no electrical components are
exposed to water.
This appliance should be installed in a location such that
the vent outlet is located in the following manner:
1. Distances to windows that open, building openings, or
public walkways should be consistent with the National
Fuel Gas Code Z223.1.
2. For U.S. installations, the vent system shall terminate
a minimum horizontal clearance of 4’ from electric
meters, regulators, and relief equipment.
3. Flue products will not cause degradation to building
materials.
This furnace design is not listed for installation in mobile
homes, recreational vehicles, or outdoors.
Use of Furnace as a Construction Heater
Allied Air does not recommended the use of these units
as a construction heater during any phase of construction.
Very low return air temperature, harmful vapors and
operation of the unit with clogged or misplaced lters will
damage the unit.
Units may be used for heating of buildings or structures
under construction, if the following conditions are met:
The unit must be permanently installed per these
installation instructions.
A room thermostat must control the furnace. The use
of xed jumpers that will provide continuous heating is
not allowed.
The return air duct must be provided and sealed to the
furnace.
