Replacement Parts
De
scription Catalog #
Single Speed 2-Button Switch SBP2-A2
Single Speed 2-Button Switch (N.O./N.C. per button) SBP2-AB2
Single Speed 2-Button Switch (Each button with two N.O. Contacts) SBP2-D2
Two-Speed 2-Button Switch SBP2-S
Three-Speed 2-Button Switch SBP2-T
Momentary On/Off 2-Button Switch SBP2-B
Maintained On/Off 2-Button Switch SBP2-H2
Maintained On/Off (N.O./N.C.) 2-Button Switch SBP2-H3
Button Cover Black for Single-, Two-, Three-Speed Switches WC2-LB
Button Cover – Red for On/Off Switches WC2-R
Button Cover – Green for On/Off Switches WC2-G
Button Cover – Black Oil Resistant WC2-BS
Legend Sheet for Button Covers 004-1060
2-Button Enclosure SBP2-E2
4-Button Enclosure SBP2-E4
6-Button Enclosure SBP2-E6
8-Button Enclosure SBP2-E8
10-Button Enclosure SBP2-E10
12-Button Enclosure SBP2-E12
Top Assembly 3/4” NPT SBP2-TA1
Top Assembly 1” NPT SBP2-TA2
Screws for Enclosure 009-4007
Switch Gasket 004-7280
A
ccessories Description Catalog #
2 Position Selector Switch SBP2-L2
3 Position Selector Switch N.C. in Center SBP2-L3
3 Position Selector Switch N.O. in Center SBP2-L3B
120 Volt Red Pilot Light-Mounts in Standard Button Hole SBP2-PLX-R
120 Volt Green Pilot Light-Mounts in Standard Button Hole SBP2-PLX-G
120 Volt White Pilot Light-Mounts in Standard Button Hole SBP2-PLX-W
120 Volt Yellow Pilot Light-Mounts in Standard Button Hole SBP2-PLX-Y
120 Volt Yellow Pilot Light-Mounts in Standard Button Hole SBP2-PLX-Y
Red Mushroom On/Off Switch-Push/Pull SBP2-SMMH
Blank to Cover Button Hole SBP2-BLNK
Cable Grip Kit* CG-KIT
*Kit Includes nut, washer and six grommets.
Installing and Wiring SBP2
®
Pendant Pushbutton Station
Prec
autions at Installation
Do not expose the unit to cold blasts of air that might cause
condensation (e.g., air conditioning duct).
Do not expose the unit to cleaning solvents that will penetrate
and damage the unit’s enclosure.
Do not use cable which is split or cracked.
Whenever possible assemble the pendant in a vertical position
to avoid contaminates falling into the enclosure.
Attach the pushbutton station to the strain relief cable so that
no tension is exerted on the pushbutton cable directly.
DANGER
HIGH VOLTAGES ARE PRESENT IN THE CONTROL PANEL, JUNCTION
BOXES, PENDANT’S ELECTRICAL COMPONENTS AND THE CONNECTION
BETWEEN THESE COMPONENTS.
Before installing, servicing or inspecting any electrical or mechanical components
of this power equipment, power must be disconnected at the source and proper
lockout/tagout procedures followed.
DO NOT make or break electrical connections (example, plugs and receptacles)
without first disconnecting power at the source and following proper
lockout/tagout procedures.
REFER TO ANSI Z244.1 PERSONNEL PROTECTION – LOCKOUT/TAGOUT
OF ENERGY SOURCES.
Only qualified personnel should install components, inspect and/or service this
equipment.
