Magnus MIPS - Technical Specifications

6
MIPS
Note:
• The Specifications are subject to change without any obligation on the part of the Manufacturer.
• The Microscopes or Accessories shown in the Catalogs or Manual are not the part of standard Equipments.
•
Recommended PC Specifications : Intel Pentium P IV 2.0 GHz or better with at least 256 MB RAM, 20 GB
Hard Disk, USB 2.0 ports Windows XP Operating System
•Storage Humidity :Up to 98%RH
• Storage temp. : -25° C to + 70° C
• Ambient operating Humidity : 20 up to 93%RH
• Ambient operating temp. : -15° C to + 55° C
• Power consumption : < 1.3 W
•Power supply :5VDC via USB bus
• Control Communication : Camera control via USB bus
• Shutter Speeds : Automatic from 1/50 to 1/100,000
• White Balance Mode : AWB auto white mode, Fixed modes selectable via software
• Iris Control : CCD Iris default
• Contour enhancement : Default on
• Back light compensation : Default on (selectable via software)
• Synchronization : Internal
• Mirror Mode : Selectable via software
•Scan Mode :Interlaced / Non Interlaced (selectable via Software)
• Gain Control : Automatic 36 dB (AGC default) or Fixed options via software
•Gamma :0.45 default (1.0 via Software)
• Signal to noise ratio : > 48 dB (AGC off)
• Sensitivity : < 1.0 Lux
• (USB 2.0, 30fps) : 720 x 576 pixels max (PAL)
• Active pixels (HxV) : 752 x 582 (PAL)
• CCD Sensor : 1/4” Interline Transfer CCD
• Video System : PAL / NTSC (Selectable from Software)
Technical Specifications
