Mahindra 35 Series User Manual

E-6
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
Sr. Location Size / Min. Torque Max. Torque
No. Description (N-m) (N-m)
Transmission
1 Retainer Main Drive Shaft To Flange Bolt – M8 x 16L x 1.25 21 25
Clutch Housing
2 Upper Cover Clutch Housing Flange Bolt – M8 x 16L x 1.25 21 25
3 Clutch Window Cover Flange Bolt – M8 x 16L x 1.25 21 25
4 Forward Reverse Shifting Flange Bolt – M8 x 16L x 1.25 21 25
5 Speed 1-2, 3-4 Bush Flange Bolt – M8 x 16L x 1.25 21 25
6 4WD Shifting Flange Bolt – M8 x 16L x 1.25 21 25
7 Retainer Mid - PTO Bearing Flange Bolt – M8 x 16L x 1.25 21 25
8 Retainer Main Drive Shaft To Flange Bolt – M8 x 16L x 1.25 21 25
Clutch Housing
9 Bearing Retainer Bull Shaft Flange Bolt – M8 x 16L x 1.25 21 25
10 Carrier RH To Transmission Case Flange Bolt – M8 x 16L x 1.25 21 25
11 Stopper Wet PTO Clutch Flange Bolt – M8 x 16L x 1.25 21 25
12 Upper Cover Transmission Case Flange Bolt – M10 x 25L 41 50
13 Rear Cover To Transmission Case Flange Bolt – M10 x 25L 41 50
14 Retainer Rear Axle Carrier M10 x 35L 41 50
15 Carrier Differential Case LH To Bolt M12 x 1.25 x 30L 92 113
Transmission Case
16 Rear Cover To Bearing Retainer Bolt M8 x 16 21 25
17 Clutch Housing & Transmission Case Flange Bolt M12 x 40L 100 124
Interface
18 Transmission Case To Mid-PTO Housing Flange Bolt M12 x 35L 100 124
19 Cover Mid-PTO To Transmission Case Flange Bolt M12 x 35L 100 124
20 Differential Case To Ring Gear Bolt M10 x 1.25 x 25.6 62 72
21 Clutch Housing To Transmission Case Hex. Flange Bolt M14 x 1.5 x 40L 130 150
22 Clutch Housing To Transmission Case Stud M14 x 50 55 65
23 Clutch Housing To Transmission Case Flange Nut M14 x 1.5 115 130
3. TORQUE CHART

Mahindra 35 Series Specifications

General

Cylinders	3
Transmission	8 Forward + 2 Reverse
Fuel Type	Diesel
Brake Type	Oil Immersed
Brakes	Oil Immersed
Steering	Power Steering
Drive Type	2WD
Engine Type	Diesel
Steering Type	Power
Fuel Tank Capacity	45 liters
