Mahindra 35 Series User Manual

E-7
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
Transmission
24 Rear Axle Carrier To Transmission Case Flange Bolt M12 x 85L 100 124
25 Rear Axle Carrier To Transmission Case Flange Bolt M12 x 30L 100 124
26 Brake Cover Assembly LH & RH Flange Bolt M10 x 30L 37 46
27 Rear Cover To RH Side Mounting Flange Bolt M10 x 30L 37 46
Bracket
28 Mid-PTO Bush Flange Bolt M8 x 1.25 x 30 21 25
29 Carrier LH To Differential Retainer Flange Bolt M8 x 1.25 x 30 21 25
30 Bull Gear To Rear Axle Bolt Bolt 3/4” UNF x 1-5/8” 265 290
31 Fork Clutch Release Bearing Bolt M10 x 1.5 x 50L 41 50
32 Bolt Special Shuttle Fork M8 21 25
33 Bolt Spring Retention M16 x 1.5 50 60
34 Bolt Hex M10 Idler Shaft 4WD & M10 x 1.25 41 50
Reverse
35 Bolt Special 4WD Shaft Retention M8 21 25
36 Connector Dipstick M33 x 1.5 50 60
37 Magnetic Drain Plug 1/2” – 14 NPTF 70 77
38 Breather Clutch Housing 1/2” – 14 NPTF 70 77
39 Lock Nut Counter Shaft M24 x 2 110 120
40 VTU Mounting Bolt M10 x 1.5 x 110 41 50
41 VTU Mounting Stud M10 x 60 57 77
42 VTU Mounting Bolt M10 x 1.5 x 30 41 50
43 Strainer Flange Removal Bolt Bolt M8 x 1.25 x 22 21 25
44 Dummy Flange Bolt For Mounting Bolt M8 x 1.25 x 22 21 25
Suction Strainer
45 PTO Control Valve Mounting Bolt M10 x 1.5 x 20 41 50
46 Rear Cover Transmission Case Pipe Coupling 1/4” BSP 40 50
47 Rear Cover Transmission Case Banjo Body M18x1.5 65 75
Sr. Location Size / Min. Torque Max. Torque
No. Description (N-m) (N-m)

Mahindra 35 Series Specifications

General

Cylinders	3
Transmission	8 Forward + 2 Reverse
Fuel Type	Diesel
Brake Type	Oil Immersed
Brakes	Oil Immersed
Steering	Power Steering
Drive Type	2WD
Engine Type	Diesel
Steering Type	Power
Fuel Tank Capacity	45 liters
