Mahindra 35 Series User Manual

F-12
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
Front Axle
1. Put hub housing (A) on a fixture.
2. Press Oil Seal (B) in Hub Housing.
NOTE: Apply Grease on oil seal before fitment in
housing.
3. Press bearing (C).
4. Put bearing retainer (D) and torque the mounting
bolt to 25 Nm.
5. Put spacer (E) in another side of hub housing.
6. Place a spindle axle (F) on fixture and put O’ring
(G) on the flange.
5. ASSEMBLY OF FRONT AXLE
A. HUB HOUSING ASSEMBLY

Mahindra 35 Series Specifications

General

Cylinders	3
Transmission	8 Forward + 2 Reverse
Fuel Type	Diesel
Brake Type	Oil Immersed
Brakes	Oil Immersed
Steering	Power Steering
Drive Type	2WD
Engine Type	Diesel
Steering Type	Power
Fuel Tank Capacity	45 liters
