F-13
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
7. Put hub housing assembly on spindle axle
carefully.
8. Insert final bevel gear (H) and retainer spindle
axle & washer.
9. Lock the spindle axle by tightening bolt (I) to the
specified torque (65 Nm).
10. Lock the bolt by bending washer (J) at three
places near bolt head.
11. Fit O’ring (K) in place.
NOTE: Apply oil to O’ring before fitment.
Front Axle
A. HUB HOUSING ASSEMBLY

Mahindra 35 Series Specifications

General

Cylinders	3
Transmission	8 Forward + 2 Reverse
Fuel Type	Diesel
Brake Type	Oil Immersed
Brakes	Oil Immersed
Steering	Power Steering
Drive Type	2WD
Engine Type	Diesel
Steering Type	Power
Fuel Tank Capacity	45 liters
