F-14
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
B. SWIVEL HOUSING ASSEMBLY
1. Fit the bearing (A) inside swivel housing (B).
NOTE: Bearing temperature 120ºC.
2. Fit the side housing pivot bearing (C).
3. Press the oil seal (D).
NOTE: Apply grease to oil seal before fitment.
4. Fit locating Dowels (E) and Studs (F) and torque
the studs to 55-65 Nm.
5. Fit the allen bolt (G) with copper washer.
NOTE: During oil filling in swivel housing, remove the
allen bolt and fit after oil filling.
Front Axle

Mahindra 35 Series Specifications

General

Cylinders	3
Transmission	8 Forward + 2 Reverse
Fuel Type	Diesel
Brake Type	Oil Immersed
Brakes	Oil Immersed
Steering	Power Steering
Drive Type	2WD
Engine Type	Diesel
Steering Type	Power
Fuel Tank Capacity	45 liters
