G-8
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
2. Illumination
light does not
light
3. Position lights
do not light
4. Hazard light
does not light
5. Direction
indicator lamps
not working
6. Brake lamps
not working
TROUBLE PROBABLE CAUSE REMEDY REF.
1. CHECKING ELECTRICAL TROUBLES (Contd.)
1. Fuse blown, Replace
switch faulty.
2. Bulb blown Replace
3. Wiring harness disconnected or Repair or replace
improperly connected (between
main switch terminal and head
light switch terminal)
1. Fuse blown Replace
2. Bulb blown, switch faulty Replace
3. Wiring harness disconnected or Repair or replace
improper.
1. Fuse blown Replace
2. Wiring harness disconnected or Replace
improperly connected (Between
head light switch terminal and
tail light)
1. Fuse blown Replace
2. Bulb blown Replace
3. Wiring harness disconnected Repair or Replace
(Between main switch terminal
and hazard unit, Between
hazard unit and hazard switch
terminal and hazard light.
4. Hazard switch defective. Replace
5. Flasher defective. Replace
1. Bulb blown Replace
2. Turn signal switch faulty Replace
3. Hazard switch faulty Replace
4. Flasher faulty Replace
5. Wiring Harness loose or Repair or Replace
wrongly connection or faulty.
1. Blown bulb Replace
2. Main brake switch faulty Replace
3. Parking brake switch faulty Replace
4. Wiring Harness loosen or Rectify the problem
wrongly connection.
1. Head lamp
does not light
Electrical System
