G-9
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
TROUBLE PROBABLE CAUSE REMEDY REF.
1. CHECKING ELECTRICAL TROUBLES (Contd.)
1. Blown bulb Replace
2. Fuse blown Replace
3. Switch faulty Replace
4. Wiring Harness Rectify or replace
1. Short circuited / heavy over load Repair or replace.
1. Timer relay faulty Replace the timer
2. Wiring faulty Repair or replace
KSB
1. KSB/FIP circuit faulty Replace
2. KSB Relay faulty Replace
3. Wiring faulty Rectify or Replace
7. Plow lamp
Electrical System
8. Fuse blown
frequently
9. Heater Indicator
continuously
“ON”
NOTE: If heater indicator is “ON” for more than 2 minutes, switch “OFF” the tractor and
remove the battery connection.

Mahindra 35 Series Specifications

General

Cylinders	3
Transmission	8 Forward + 2 Reverse
Fuel Type	Diesel
Brake Type	Oil Immersed
Brakes	Oil Immersed
Steering	Power Steering
Drive Type	2WD
Engine Type	Diesel
Steering Type	Power
Fuel Tank Capacity	45 liters
