G-10
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
Electrical System
The Instrument Cluster is a descriptive unit that gives
the user various indications about the working of the
tractor and its various features. It consists of the
following:
1. High Beam Indicator
2. LH / RH Turn Signal Indicator
3. Coolant Temperature Gauge
4. Fuel Level Gauge
5. Engine RPM Meter
6. Hour Counter
7. Engine Low Oil Pressure Gauge
8. Voltmeter
9. Battery Charge Indicator
10. 4WD Indicator
11. Parking Brake Indicator
12. Heater Indicator
2. Instrument Cluster
A.General
The various Instruments gauges and switches
are mounted on the instrument panel and
scuttle assembly.
The panel is secured by four screws on the
scuttle assembly under the steering wheel. The
operator can easily pay attention on the gauges
and indicators and can reach to the switches
and control while driving.
The operator must be thoroughly acquainted
with the location and use of all instruments and
controls regardless of experience, must read
operators manual carefully before attempting
to operate the tractor.
2
1
3
4
10
11
7
12
5 6
9
8
