H-15
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
Steering Cylinder dismantling
1. Loosen the allen screws from both sides of the
cylinder head.
2. Gently tap by plastic hammer the rod till the
cylinder head will come out.
3. Remove cylinder head.
4. Inspect cylinder head rod wiper, rod seal, bearing
ring and o’ring for wear or cracks.
5. Remove wear or damaged seals or o’rings and
install with new one. If these seals or O'Rings
damaged, this will result into external leakages.
Steering
