Mahindra 35 Series User Manual

I-23
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
11. REMOVAL AND REFITMENT OF HYDRAULIC
LIFT UNIT
bolts.
and slow fast valve knob.
wiring from front platform.
10. Lift the fender rear platform, sheet assembly.
Removing of Control Levers Knob
Hydraulics
1. Remove rear isolator mounting bolt.
2. Then remove rear platform to front platform
3. Remove the PC, DC, Range, Speed Lever Knobs
4. Remove diff. lock pedal.
5. Remove four wheel lever plate.
6. Remove fender to front platform bolts.
7. Remove ROPS connecting plate bolt.
8. Remove wiring connections and dismantle
9. Remove gear lever rubber boot and knob.

Mahindra 35 Series Specifications

General

Cylinders	3
Transmission	8 Forward + 2 Reverse
Fuel Type	Diesel
Brake Type	Oil Immersed
Brakes	Oil Immersed
Steering	Power Steering
Drive Type	2WD
Engine Type	Diesel
Steering Type	Power
Fuel Tank Capacity	45 liters
