Mahindra 35 Series User Manual

I-24
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
11. Disconnect necessary connections while lifting
the assembly.
12. Then first dismantle all hydraulics pipes.
13. Remove hydraulic mounting bolts.
14. Lift the hydraulic unit assembly.
15. Make repairs as necessary.
16. Clean mating surfaces of housing assembly and
differential housing using primer.
17. Install hydraulic lift unit using cap screws.
Torque the bolt to 41-50 Nm (30-37 lbs.ft)
18. Connect lift unit supply line. Tighten to torque
to 60 Nm (45 lbs.ft).
assembly.
Hydraulics
19. Install top link and connect lift links.
20. Follow the reverse sequence of dismantling for

Mahindra 35 Series Specifications

General

Cylinders	3
Transmission	8 Forward + 2 Reverse
Fuel Type	Diesel
Brake Type	Oil Immersed
Brakes	Oil Immersed
Steering	Power Steering
Drive Type	2WD
Engine Type	Diesel
Steering Type	Power
Fuel Tank Capacity	45 liters
