I-25
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
Hydraulics
12. REMOVE, INSPECT AND INSTALL HYDRAULIC
CONTROL LEVER SUPPORT ASSEMBLY
1. Remove Hydraulic Lift Unit as per the guided
procedure.
2. Remove position and draft control linkages
levers by loosening lock clips and washers.
3. Remove socket head screw (A), two cap
screw (B), lever position control (C) and
hub (D).
4. Loosen set screw (E) in link (F).
