B-17
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
Removal & Refitment of Hood
Removal & Refitment of Hood
1. Pull the knob (A) and lift the hood.
2. Disconnect the Battery negative & positive
terminals.
3. Disconnect the wiring harness to the head lamp
& remove the wiring harness from hood clamps.
4. Loosen the nut (B) of gas spring (C) & remove
gas spring.
The hood needs to be held in place
with external support.
5. Remove the 4 nuts (D) of hood bracket & gently
take out hood.
6. Hold the hood firm before attempting its removal.
Improper / inadequate
supporting/holding the hood in place during its
removal can cause injury.
7. Follow the reverse sequence of removal for
refitment.
Align the hood resting area
equally and properly, before tightening the four
hood mounting nuts.
