B-22
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
Removal & Refitment of Starter Motor
Removal of the Starter Motor
1. Pull the knob, unlock the Hood lock and lift the
hood.
2. Remove LH side panel.
3. First remove the battery cable from its negative
terminal & then remove battery cable from
positive terminal.
4. Disconnect the cables connected to the Starter
motor.
5. Dismantle the Starter Motor mounting bolts (A),
slide it forward and remove from the engine.
Refitment of the Starter Motor
1. Refit the removed parts in the reverse sequence
of removal.
2. Refit the Battery Negative cable only at the end
of assembly.

Mahindra 35 Series Specifications

General

Cylinders	3
Transmission	8 Forward + 2 Reverse
Fuel Type	Diesel
Brake Type	Oil Immersed
Brakes	Oil Immersed
Steering	Power Steering
Drive Type	2WD
Engine Type	Diesel
Steering Type	Power
Fuel Tank Capacity	45 liters
