E-28
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
4. Remove inner circlip (C) of inner bearing (D) and
take out inner bearing.
5. Loosen bolt (E) of retainer bearing (F) and take
out retainer by slight tapping.
6. Remove outer bearing (G) of Rear Axle.
NOTE: Check ball bearing and oil seal for damages
and pitting, if require replace it.
4. Cleaning and Inspection
1. Clean all parts with suitable solvent.
2. Inspect bearing for wear, pitting or damage.
3. Inspect gear for worn, chipped or broken teeth.
Check splines for burrs and correct fitting.
4. Check bull pinion shaft for damage, pitting and
burrs and backlash.
5. Check Ball Bearings and oil seals for damages and
pitting, if require replace it.
Rear Axle
