35 Series-HST, Model - 3535, 4035, 4535 & 5035
42
Controls
Tilt Steering
The steering can be tilted towards the operator as per the
need and convenience of operator and is recommended to
be done in tractor parked condition.
Tilt Adjustment
1. Park the tractor safely.
2. Press the Tilt steering pedal by foot.
3. Pull the steering wheel to desired position.
4. Release foot pressure on the pedal.
5. To position the steering wheel back, press the tilt
steering pedal to allow the steering wheel to travel back
to the top position. It will go back automatically.
4WD Engagement Lever
This lever is located on LH side of operator’s seat. It is used
to engage or disengage the drive to front wheels and is
recommended to be done in tractor stand still condition.
1. Stop the tractor motion completely.
2. Lift the lever upwards to engage the drive.
3. Push the lever down to disengage the drive.
Attempting to adjust the steering wheel while
driving the tractor may cause the operator to
lose control of the tractor.
Lock the steering wheel in position before
driving the tractor.
Do not engage or disengage the 4WD
Engagement lever while the tractor is in motion.
Disengaged Position
