E-29
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
Rear Axle
5. Assembly
1. Install big end ball bearing in Real Axle Carrier
(RAC) and lock with circlip (H).
2. Clean retainer surface area and fit new oil seal
in retainer Rear Axle (2 nos.).
3. Install oil seals with retainer in Rear Axle.
4. Install outer ball bearing with fixture for
positioning of bearing.
5. Apply liquid gasket on retainer.

Mahindra 5035 Specifications

General

Transmission	8 Forward + 2 Reverse
No. of Cylinders	3
Steering Type	Power Steering
PTO RPM	540
Engine Type	Diesel
Brakes	Oil Immersed Brakes
Clutch Type	Single
