Mahindra 5035 Service Manual

B-5
35 Series 4WD, Model - 3535, 4035, 4535 and 5035 SM June’08
Splitting Between Front Axle & Engine
10. Remove the radiator mounting bolts and remove
the radiator.
11. Remove the front bottom grill and bonnet locking
bracket.
12. Disconnect the LH / RH hoses to the power
steering cylinder and plug the hoses to prevent
oil spillage.
13. Remove the propeller shaft guards.
14. Remove the propeller shaft bearing from support
bracket.

Mahindra 5035 Specifications

General

Transmission	8 Forward + 2 Reverse
No. of Cylinders	3
Steering Type	Power Steering
PTO RPM	540
Engine Type	Diesel
Brakes	Oil Immersed Brakes
Clutch Type	Single
