43
Illus.
No.
Part
Description
Quantity
MAHINDRA GYROVATOR SLX
1 007904775C1 OIL SEAL- 35X57X11 1
2 007903965C1 PIC FLANGE 1
3 007903967C1 PIC FLANGE GASKET GEAR BOX - 0.5 MM 1
4 007903991C1 PIC FLANGE GASKET GEAR BOX - 0.25 MM 1
5 007904779C91 TAPPER ROLLER BEARING-72X35X25.24 3
6 P3110111A PIC SHAFT WITH CIRCLIP 1
7 007903960C2 GEAR BOX HOUSING 1
8 007904762C1 BREATHER ASSY WITH DIPSTICK 1
8.1 007904734C11 DIP STICK 1
8.2 007904764C1 O-RING 20X2 1
8.3 007904732C1 AIR BREATHER ADOPTER BIG 1
8.4 007904733C91 AIR BREATHER BIG 1
9 007904040C1 SPACER ID35.5X OD45 X12 (GEAR BOX) 2
10 007903952C1 SPUR GEAR -SLX 20T 1
11 007903968C1 GASKET-COUNTER SHAFT FLANGE - 0.5 MM 1
12 007903993C1 GASKET-COUNTER SHAFT FLANGE-0.25MM 1
13 007904269C1 EXTERNAL CIRLIP A 29 (26.9)X1.5 2
14 007905111C1 RUBBERIZED CORK GASKET - CLOSING PLATE 1
15 007903970C2 CLOSING PLATE 1
16 007904086C1 BOLT M10 X 1.5 X 30 (GRADE 8.8) 20
17 007904102C1 SPRING WASHER M10 20
18 007903953C1 SPUR GEAR-18 T 1
19 007904780C1 MAGNETIC DRAIN PLUG 1
20 007904042C1 SPACER DRIVE SHAFT BEVEL GEAR SIDE 1
21 007904224C1 CIRCLIP EXTERNAL- 48.3 X1.75 1
22 007904347C1 LOCK PLATE 4
23 007904533C12 SUPPORT TUBE ASSEMBLY - DRIVE SIDE 1.5M 1
23.1 007904433C92 SUPPORT TUBE ASSEMBLY - DRIVE SIDE 1.75M 1
23.2 007904000C12 SUPPORT TUBE ASSEMBLY - DRIVE SIDE 2.0M 1
24 007904535C1 DRIVE SHAFT 1.5M MS CM 1
24.1 007904435C1 DRIVE SHAFT 1.75M MS CM 1
24.2 007903972C1 DRIVE SHAFT 2.0M MS CM 1
25 007904031C1 SUPPORT TUBE GASKET- DRIVE PLATE SIDE 1
26 007904344C1 COUNTER SHAFT FLANGE 1
27 007904076C91 TAPPER ROLLER BEARING 80 X 40 X 24.75 1
28 007904213C1 OIL SEAL-48X75X10 1
29 007903969C1 GASKET HOLLOW SHAFT BEVEL END-0.5 MM 1
30 007904029C1 GASKET HOLLOW SHAFT BEVEL END -0.25MM 1
31 007904075C91 TAPPER ROLLER BEARING 130 X 75 X 27.25 1
32 007905157C1 SLX SPIRAL BEVEL GEAR-T19 1
ABBREVIATION : M - METER, MS - MULTI SPEED,CM - CENTER MOUNTED,OS-OFFSET
