Mahindra Gyrovator SLX Series User Manual

45
Illus.
No.
Part
Description
Quantity
MAHINDRA GYROVATOR SLX
33 007904216C1 NUT SLOTTED M35 X 1.5 X 15 1
34 007904219C1 PIN R 1
35 P3110112A COUNTER SHAFT WITH CIRCLIP 1
36 007905158C1 SLX SPIRAL BEVEL GEAR-T11 1
37 007904077C91 TAPPER ROLLER BEARING 112.7 X 57.15 X 30 1
38 P3110114A CIRCLIP 35x1.5N IS:3075 2
39 007903950C1 SPUR GEAR 17 T 1
40 007903949C1 SPUR GEAR 21 T 1
ABBREVIATION : M - METER, MS - MULTI SPEED,CM - CENTER MOUNTED,OS-OFFSET
