47
Illus.
No.
Part
Description
Quantity
MAHINDRA GYROVATOR SLX
1 P3110099A LHS HOLDER 1
2 007904073C91 HEAVY DUTY SEAL 1
3 P3110100A HUB LHS ROTOR 1
4 007904777C91 BALL BEARING 100X45X25 1
5 007904776C1 100 MM INTERNAL CIRCLIP 1
6 P3110101A GASKET-LHS HOLDER 2
7 P3110051A PLATE ASSY - DRIVE SIDE - SLX 1
8 007904215C1 WASHER PLAIN M12 O.D. 24 (1.6 t) 8
9 007904104C1 SPRING WASHER M12 8
10 007904089C1 BOLT M12 X 1.5 X 30 (GRADE 10.9) 8
11 007904284C1 BOLT M10 X 1.5 X 50 (GRADE 8.8) 5
12 007904035C1 GASKET-IDLER SHAFT 1
13 007904451C1 SHAFT -IDLER GEAR 1
14 007904102C1 SPRING WASHER M10 5
15 007904290C1 NUT M10 X 1.5 NYLOC 5
To Next Page
