Mahindra Gyrovator SLX Series User Manual

51
Illus.
No.
Part
Description
Quantity
MAHINDRA GYROVATOR SLX
1 007904087C1 BOLT M12 X 1.5 X 40 (GRADE 10.9) 14
2 007904285C1 BOLT M12 X 1.5 X 160 (GRADE 10.9) 2
3 P3110054A FRAME ASSEMBLY FOR SLX 1.5M 1
3.1 P3110053A FRAME ASSEMBLY FOR SLX 1.75M 1
3.2 P3110052A FRAME ASSEMBLY FOR SLX 2.0M 1
4 007904782C1 LYNCH PIN 2
5 007904034C1 LOWER LINK HITCH BRACKET - REAR 2
6 007904033C1 LOWER LINK HITCH BRACKET - FRONT 2
7 007904061C1 PIN LOWER HITCH BRACKET 2
8 007904286C1 BOLT M16 X 1.5 X 55 (GRADE 10.9) 8
9 007904291C1 NUT M16 X1.5 NYLOC 8
10 007904106C1 SPRING WASHER M16 8
11 007904192C1 HOLDING BLOCK - DRIVE SIDE 1
12 007904104C1 SPRING WASHER M12 16
13 007904289C1 NUT M12 X 1.5 NYLOC 16
ABBREVIATION : M - METER, MS - MULTI SPEED,CM - CENTER MOUNTED,OS-OFFSET
