Mahindra Gyrovator SLX Series User Manual

55
Illus.
No.
Part
Description
Quantity
MAHINDRA GYROVATOR SLX
1 007904087C1 BOLT M12 X 1.5 X 40 (GRADE 10.9) 9
2 P3110087A SKID ASSEMBLY RHS - SLX 1
3 007904022C1 SKID SHOE ADJUSTER PLATE 1
4 007904193C1 HOLDING BLOCK - NON DRIVE SIDE 1
5 007904104C1 SPRING WASHER M12 11
6 007904289C1 NUT M12 X 1.5 NYLOC 13
7 007904291C1 NUT M16 X1.5 NYLOC 5
8 007904106C1 SPRING WASHER M16 9
9 007904327C1 PIN STAND 2
10 007904050C11 STAND MOUNTING BRACKET 1
11 007904051C11 STAND 1
12 007904782C1 LYNCH PIN 3
13 007904534C11 SUPPORT TUBE ASSEMBLY - NON DRIVE SIDE 1.5M 1
13.1 007904434C91 SUPPORT TUBE ASSEMBLY - NON DRIVE SIDE 1.75M 1
13.2 007904001C11 SUPPORT TUBE ASSEMBLY - NON DRIVE SIDE 2.0M 1
14 007904287C1 BOLT M16 X 1.5 X 30 (Grade 10.9) 4
15 007904286C1 BOLT M16 x 1.5 x 55 (Grade 10.9) 4
16 007904041C1 MAST BRACKET - FRONT 2
17 007904095C1 BOLT M16 X 1.5 X 125 (GRADE 10.9) 1
18 007904043C1 MAST BRACKET - REAR 2
19 007904062C1 MAST SPACER 1
20 007904348C1 LOCK PLATE - L 4
21 007904285C1 BOLT M12 X 1.5 X 160 (GRADE 10.9) 2
22 007904781C1 PIN TOP LINK IMPLEMENT END 1
23 P3110088A SKID SHOE WEAR PLATE SLX 1
24 007904089C1 BOLT M12 X 1.5 X 30 (GRADE 10.9) 2
ABBREVIATION : M - METER, MS - MULTI SPEED,CM - CENTER MOUNTED,OS-OFFSET
