59
MAHINDRA GYROVATOR SLX
Illus.
No.
Part
Description
Quantity
1 007904010C11 ROTOR SHAFT ASSY. SLX 2M (10MM FLANGE THK.) 1
2 007904013C1 BLADE - L - TYPE RH 24
3 007904012C1 BLADE - L - TYPE LH 24
4 007904187C1 BOLT M14 X 1.5 X 40 (GRADE 10.9) 96
5 007904190C1 SPRING WASHER M14 96
6 007904188C1 NYLOCK NUT M14X1.5 96
7 P3110098A ROTOR SHAFT SLX 2M (12MM FLANGE THK.)
ROTOR SHAFT ASSEMBLY 1.75M (REGULAR & ANTI-CLOGGING)
8 007904437C11 ROTOR SHAFT ASSY. FOR SLX 1.75M REGULAR 1
(10MM FLANGE THK.)
2 007904013C1 BLADE - L - TYPE RH 21
3 007904012C1 BLADE - L - TYPE LH 21
4 007904187C1 BOLT M14 X 1.5 X 40 (GRADE 10.9) 84
5 007904190C1 SPRING WASHER M14 84
6 007904188C1 NYLOCK NUT M14X1.5 84
9 007904738C11 ROTOR SHAFT ASSEMBLY FOR SLX 1.75M 1
ANTI-CLOGGING ( (10MM FLANGE THK.)
12 P3110064A ROTOR SHAFT ASSY. FOR SLX 1.75 M REGULAR 1
(12MM FLANGE THK.)
13 P3110105A ROTOR SHAFT ASSY. FOR SLX 1.75M ANTI-CLOGGING
(12MM FLANGE THK.) 1
ROTOR SHAFT ASSEMBLY 1.5M (REGULAR & ANTI-CLOGGING)
10 007904489C11 ROTOR SHAFT ASSY. FOR SLX 1.5M REGULAR 1
(10MM FLANGE THK.)
2 007904013C1 BLADE - L - TYPE RH 18
3 007904012C1 BLADE - L - TYPE LH 18
4 007904187C1 BOLT M14 X 1.5 X 40 (GRADE 10.9) 72
5 007904190C1 SPRING WASHER M14 72
6 007904188C1 NYLOCK NUT M14X1.5 72
11 007904739C11 ANTI CLOGGING ROTOR SHAFT ASSY. FOR SLX 1
(10MM FLANGE THK.)
14 P3110093A ROTOR SHAFT ASSY. FOR SLX 1.5M REGULAR 1
(12MM FLANGE THK.)
15 P3110103A ROTOR SHAFT ASSY. FOR SLX 1.5M ANTI-CLOGGING 1
(12MM FLANGE THK.)
ABBREVIATION : M - METER,RH-RIGHT HAND SIDE,LH-LEFT HAND SIDE
