1.0 IDENTIFICATION

1.1 TECHNICAL DATA

1) Pin Top Link

2) Mast Bracket Front

3) Lifting stirrup.

4) Main Gearbox.

5) Side Cover Assembly

6) Skid Shoe Adjuster Plate

7) Skid Shoe Adjuster

8) Rotor Shaft Assembly

9) Lower Link Hitch Pin

1234

I III

IIIV

10) Stand

11) Pic Shaft (Power Input Connection)

12) Adjuster Rod

I = Front side

II = Back side / Rear side

III = Left side

IV = Right side

Fig. 3
