55
8.1.10. Return parking stand to storage position in the
boom cross tube. Secure using hairpin cotter.
Hairpin cotter
in storage position
Parking stand
in storage position
IMPORTANT: To avoid hydraulic hose damage, be alert and make sure hoses do not catch on tractor
and/or loader during mounting or dismounting.
After loader is mounted, reinstall original rear 3-point
ballast.
Install original rear 3-point ballast
35 Series 4WD, Model - 3535 & 4035 Loader June’08
