The tool kit consists of the a wheel spanner and the jack extension levers.
Spare wheel is mounted on a bracket on the rear tail gate of the vehicle. It is held in
place by three securing nuts. A snap fit wheel cover is fitted on the spare wheel.
• Cautiously pry out the wheel cover using both hands as shown
• Remove the securing nuts on the spare wheel
• Remove the spare wheel
Always loosen the wheel nuts before raising the vehicle. Turn the wheel nuts counter
clockwise to loosen. To get maximum leverage, fit the spanner to the nut so that the
handle is on the left side. Grab the spanner near the end of the handle and push
down on the handle. Be careful that the spanner does not slip off the nut. Do not
remove the nuts, but loosen them by one or two turns.
